ESD Resin V1, 1L | Form 4

Looking to boost your electronics manufacturing lines? Look no further than Formlabs ESD Resin compatible with Form 4 SLA 3D printers! With Formlabs' ESD (Electrostatic Discharge) Resin, you can prototype and validate production workflows, print static-dissipative parts that repel dust and powder and create enclosures to safeguard sensitive electronics from static discharge.

Don't let static ruin your electronics manufacturing game - switch to ESD Resin today!

Support print resolutions: 100 µm and 50µm

Post-curing is required.

Applications

• Tooling & fixturing for electronics manufacturing
• Custom trays for component handling and storage
• Anti-static prototypes and end-use components

Material Properties

• Surface Resistivity: 105 - 108 Ohms/sq
• Ultimate Tensile Strength: 44.2 MPa
• Tensile Modulus: 1.937 GPa
• Strain at break: 12%
• Notched Izod: 26 J/m
• Heat Deflection Temperature 0.45 MPA: 62.2ºC
• Heat Deflection Temperature 1.8 MPA: 54.2ºC

3D Printer Compatibility

• Formlabs® Form 4
