BioMed Amber V2, 1L | Form 4

Choose Formlabs BioMed Amber resin for producing end-use devices where performance and biocompatibility are critical.

• Medical-Grade Material
  Leverage a material manufactured within our Quality Management Systems, strictly adhering to ISO 13485.
• Semi-Transparent
  Visibility through parts allows light to pass through.
• Excellent Definition
  Produce parts and assemblies with complex designs and geometries.
• Semi-Transparent
  Visibility through parts allows light to pass through.

Formlabs BioMed Amber Resin is a strong, stiff material for biocompatible applications requiring short-term skin or mucosal membrane contact. Parts printed with this material are compatible with standard solvent disinfection and sterilization methods.

Formlabs BioMed Amber Resin is recommended for strong, rigid parts such as functioning threads.

Supports print resolutions: 100 µm and 50µm
Post-curing is required.

Applications

• End-use medical devices
• Implant sizing models
• Cut + drill guides
• Specimen collection kits

Material Properties | Post-cured at 70ºC for 30 min

• Ultimate Tensile Strength: 73 MPa
• Young’s Modulus: 2900 MPa
• Elongation: 12%
• Flexural Strength:103 MPa
• Flexural Modulus: 2500 MPa
• Hardness Shore D, 67 D
• Notched Izod: 28 J/m
• Heat Deflection Temp @ 0.45 MPa: 78 ºC

*Material properties may vary based on part geometry, print orientation, print settings, temperature, and disinfection or sterilization methods used.

3D Printer Compatibility

• Formlabs Form 4B
• Formlabs Form 4BL
